ATF16V8B-15PC

high-performance, CMOS programmable logic device, DIP-20, -2.0 V to +7.0 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.60~0.96 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.60~0.96

PartNumber:: ATF16V8B-15PC

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Kelvin's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-01

From Other Seller

Part Number:ATF16V8B-15PC
US $0.60 - 0.96
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ATF16V8B-15PC is a high-performance CMOS (electrically erasable) programmable logic device (PLD) that utilizes Atmel’s proven electrically-erasable Flash memory technology. Speeds down to 7.5 ns are offered. All speed ranges are specified over the full 5V ± 10% range for industrial temperature ranges, and 5V ± 5% for commercial temperature ranges.

Parametrics

ATF16V8B-15PC absolute maximum ratings: (1)Temperature Under Bias: -55 to +125℃; (2)Storage Temperature: -65 to +150℃; (3)Voltage on Any Pin with Respect to Ground: -2.0 V to +7.0 V; (4)Voltage on Input Pins with Respect to Ground During Programming: -2.0 V to +14.0 V; (5)Programming Voltage with Respect to Ground: -2.0 V to +14.0 V.

Features

ATF16V8B-15PC features: (1)Industry-standard Architecture: Emulates Many 20-pin PALs; Low-cost Easy-to-use Software Tools ; (2)High-speed Electrically-erasable Programmable Logic Devices: 7.5 ns Maximum Pin-to-pin Delay ; (3)Several Power Saving Options ; (4)CMOS and TTL Compatible Inputs and Outputs: Input and I/O Pull-up Resistors; (5)Advanced Flash Technology: Reprogrammable; 100% Tested; High-reliability CMOS Process; 20 Year Data Retention; 100 Erase/Write Cycles; 2,000V ESD Protection; 200 mA Latchup Immunity; (6)Commercial, and Industrial Temperature Ranges; (7)Dual-in-line and Surface Mount Packages in Standard Pinouts; (8)PCI-compliant.
