M25P64-VMF6TP

Flash Memory, -0.5 to VCC + 0.6V, SOP-16

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.53~1.75 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.53~1.75

PartNumber:: M25P64-VMF6TP

Brand:: Numonyx B.V - Numonyx | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Kelvin's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-24

From Other Seller

Part Number:M25P64-VMF6TP
US $1.53 - 1.75
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
Quantity:

piece

Product Summary

The M25P64-VMF6TP is a 64 Mbit (8M x 8) Serial Flash Memory, with advanced write protection mechanisms, accessed by a high speed SPI-compatible bus. The M25P64-VMF6TP can be programmed 1 to 256 bytes at a time, using the Page Program instruction. An enhanced Fast Program/Erase mode is available to speed up operations in factory environment. The M25P64-VMF6TP enters this mode whenever the VPPH voltage is applied to the Write Protect/Enhanced Program Supply Voltage pin (W/VPP).

Parametrics

M25P64-VMF6TP absolute maximum ratings: (1)Storage Temperature: -65 to 150 ℃; (2)Input and Output Voltage (with respect to Ground): -0.5 to VCC + 0.6V; (3)Supply Voltage: -0.2 to 4.0 V; (4)Fast Program/Erase Voltage: -0.2 to 10.0 V; (5)Electrostatic Discharge Voltage (Human Body model): -2000 to 2000 V.

Features

M25P64-VMF6TP features: (1)64 Mbit of Flash memory; (2)2.7 V to 3.6 V single supply voltage; (3)SPI bus compatible serial interface; (4)50 MHz clock rate (maximum); (5)VPP = 9 V for Fast Program/Erase mode (optional); (6)Page Program (up to 256 Bytes): in 1.4 ms (typical), in 0.35 ms (typical with VPP = 9 V); (7)Sector Erase (512 Kbit); (8)Bulk Erase (64 Mbit); (9)Electronic Signatures: JEDEC standard two-Byte signature (2017h), RES instruction, one-Byte, signature (16h), for backward compatibility.
