MX29LV160DBTI-70G

16M-bit, CMOS, single voltage 3V only, flash memory, TSOP-48, Single power supply operation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.57~0.62 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.57~0.62

PartNumber:: MX29LV160DBTI-70G

Brand:: Macronix International - MXIC | Pack: TSOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Kelvin's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-24

From Other Seller

Part Number:MX29LV160DBTI-70G
US $0.57 - 0.62
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MX29LV160DBTI-70G is a 16-mega bit Flash memory organized as 2M bytes of 8 bits or 1M words of 16 bits. It offers the most cost-effective and reliable read/write non-volatile random access memory. The MX29LV160DBTI-70G is designed to be reprogrammed and erased in system or in standard EPROM programmers. The MX29LV160DBTI-70G offers access time as fast as 70ns, allowing operation of high-speed microprocessors without wait states.

Parametrics

MX29LV160DBTI-70G absolute maximum ratings: (1)Storage Temperature Plastic Packages:-65℃ to +150℃; (2)Ambient Temperature with Power Applied:-65℃ to +125℃; (3)Voltage with Respect to Ground: VCC:-0.5 V to +4.0 V, A9, OE, and RESET:-0.5 V to +12.5 V, All other pins:-0.5 V to VCC +0.5 V; (4)Output Short Circuit Current:200 mA.

Features

MX29LV160DBTI-70G features: (1)Extended single - supply voltage range 2.7V to 3.6V; (2)2,097,152 x 8/1,048,576 x 16 switchable; (3)Single power supply operation; (4)3.0V only operation for read, erase and program operation; (5)Fast access time: 70/90ns; (6)Low power consumption; (7)30mA maximum active current; (8)0.2uA typical standby current; (9)Command register architecture; (10)Byte/word Programming (9us/11us typical); (11)Sector Erase (Sector structure 16K-Bytex1,; (12)8K-Bytex2, 32K-Bytex1, and 64K-Byte x31); (13)Auto Erase (chip & sector) and Auto Program; (14)Automatically erase any combination of sectors with; (15)Erase Suspend capability.; (16)Automatically program and verify data at specified address; (17)Erase Suspend/Erase Resume; (18)Suspends sector erase operation to read data from, or program data to, any sector that is not being erased, then resumes the erase; (19)Status Reply: Data polling & Toggle bit for detection of program and erase operation completion.
