Product Summary

The MBRS240LT3G is a Surface Mount Schottky Power Rectifier. It employs the Schottky Barrier principle in a metal-to-silicon power rectifier. Features epitaxial construction with oxide passivation and metal overlay contact. The MBRS240LT3G is ideally suited for low voltage, high frequency switching power supplies; free wheeling diodes and polarity protection diodes.

Parametrics

MBRS240LT3G absolute maximum ratings: (1)Peak Repetitive Reverse Voltage:40V; (2)Working Peak Reverse Voltage:40V; (3)DC Blocking Voltage:40V; (4)Average Rectified Forward Current(At Rated VR, TC=100℃):2.0A; (5)Peak Repetitive Forward Current(At Rated VR, Square Wave, 20 kHz, TC = 105℃):4.0A; (6)Non-Repetitive Peak Surge Current (Surge Applied at Rated Load Conditions Halfwave, Single Phase, 60 Hz):25A; (7)Storage/Operating Case Temperature:-55℃ to +150℃; (8)Operating Junction Temperature:-55℃ to +125℃; (9)Voltage Rate of Change(Rated VR, TJ = 25℃):10,000 V/μs.

Features

MBRS240LT3G features: (1)Compact Package with J-Bend Leads Ideal for Automated Handling; (2)Highly Stable Oxide Passivated Junction; (3)Guard-Ring for Overvoltage Protection; (4)Low Forward Voltage Drop; (5)Pb-Free Package is Available.

Diagrams

MBRS240LT3G marking diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MBRS240LT3G
MBRS240LT3G

ON Semiconductor

Schottky (Diodes & Rectifiers) 2A 40V Low Vf

Data Sheet

0-1: $0.33
1-25: $0.22
25-100: $0.18
100-500: $0.12
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MBRS10100
MBRS10100

Taiwan Semiconductor

Schottky (Diodes & Rectifiers) 10 Amp 100 Volt Single

Data Sheet

0-800: $0.45
800-1600: $0.37
1600-3200: $0.32
3200-5600: $0.29
MBRS10100CT
MBRS10100CT

Taiwan Semiconductor

Schottky (Diodes & Rectifiers) 10 Amp 100 Volt Dual

Data Sheet

0-800: $0.45
800-1600: $0.37
1600-3200: $0.32
3200-5600: $0.29
MBRS1035
MBRS1035

Taiwan Semiconductor

Schottky (Diodes & Rectifiers) 10 Amp 35 Volt Single

Data Sheet

0-800: $0.37
800-1600: $0.30
1600-3200: $0.26
3200-5600: $0.23
MBRS1035CT
MBRS1035CT

Taiwan Semiconductor

Schottky (Diodes & Rectifiers) 10 Amp 35 Volt Dual

Data Sheet

0-800: $0.43
800-1600: $0.35
1600-3200: $0.31
3200-5600: $0.28
MBRS1045
MBRS1045

Taiwan Semiconductor

Schottky (Diodes & Rectifiers) 10 Amp 45 Volt Single

Data Sheet

0-800: $0.37
800-1600: $0.30
1600-3200: $0.26
3200-5600: $0.23
MBRS1045CT
MBRS1045CT

Taiwan Semiconductor

Schottky (Diodes & Rectifiers) 10 Amp 45 Volt Dual

Data Sheet

0-800: $0.43
800-1600: $0.35
1600-3200: $0.31
3200-5600: $0.28
