M29W320EB70N6E

non-volatile memory, TSOP-48, 2.7 to 3.6V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.07~1.12 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.07~1.12

PartNumber:: M29W320EB70N6E

Brand:: STMicroelectronics - ST | Pack: TSOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Kelvin's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-24

From Other Seller

Part Number:M29W320EB70N6E
US $1.07 - 1.12
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The M29W320EB70N6E is a 32 Mbit (4Mb x8 or 2Mb x16) non-volatile memory that can be read, erased and reprogrammed. These operations can be performed using a single low voltage(2.7 to 3.6V) supply. On power-up the memory defaults to its Read mode. The M29W320EB70N6E features an asymmetrical block architecture. The M29W320E has an array of 8 parameter and 63 main blocks. It locates the Parameter Blocks at the top of the memory address space while it locates the Parameter Blocks starting from the bottom.

Parametrics

M29W320EB70N6E absolute maxing ratings: (1)TBIAS Temperature under bias: min=-50℃, max=125℃; (2)TSTG Storage temperature: min=-65℃ max=150℃; (3)VIO Input or Output voltage(1)(2): min=-0.6V, max=VCC+0.6V; (4)VCC Supply voltage: min=-0.6V, max=4V; (5)VID Identification voltage: min=-0.6V, max=13.5V; (6)VPP(3) Program voltage: min=-0.6V, max=13.5V.

Features

M29W320EB70N6E features: (1)Supply voltage: VCC = 2.7V to 3.6V for Program, Erase and Read; VPP =12V for Fast Program (optional); (2)Access times: 70, 90ns; (3)Programming time: 10μs per byte/word typical; Double word/ Quadruple byte Program; (4)Memory Blocks: Memory Array: 63 Main Blocks; 8 Parameter Blocks (Top or Bottom Location); (5)Erase Suspend and Resume modes: Read and Program another Block during Erase Suspend; (6)Unlock Bypass Program command: Faster Production/Batch Programming; (7)VPP/WP pin for fast Program and Write Protect; 8)Temporary Block Unprotection mode; (9)Common Flash Interface: 64 bit Security code.
